如何更換損壞的地磅傳感器
How to weigh sensor replacement

在更換損壞的地磅稱重傳感器時應按照生產廠家的要求進行，以免產生新的損壞。更換步驟如下：
In the replacement of damaged loadometer weighing sensor should be carried out in accordance with the manufacturers requirements, in order to avoid new damage. Replace the following steps:
1.打開損壞了的傳感器上方蓋板，用千斤頂頂起秤臺，取下連接件。如有限位支座，則拆下限位支座。
The sensor cover above 1 open broken, jack up platform, remove the connector. As a support, remove the lower limit.
2.打開接線盒，將損壞了的傳感器的電纜線與接線盒斷開，拆除固定此電纜線的電纜夾，在傳感器端抽出電纜線。
2 open the junction box, cable and wiring box sensor will be broken off, remove the cable fixing the cable clamp, at the end of the sensor out cable.
注意：在抽線時，附上一根引線穿過秤臺，以便在更換新傳感器時，很方便地將電纜線穿越秤臺進入接線盒。
Note: in a line, with a lead through the weighing platform, in order to replace the new sensor, it is convenient to the cable through the scale platform into the junction box.
3.用套筒扳手松開固定傳感器的高強度螺母，拆下傳感器。
把新的傳感器裝上，用高強度螺栓螺母固定住傳感器，再用扭矩扳手按規定的扭矩擰緊螺母。
3 high strength nut sleeve wrench to loosen the fixed sensor, remove the sensor. The new sensor is installed on a fixed sensor, high strength bolt and nut, and then tighten the nut torque wrench torque according to regulations.
4.參照2的方法，將新傳感器電纜線穿越秤臺進入接線盒，用電纜夾固定住電纜線。
4 according to the 2 method, a new sensor cable through the scale platform into the junction box, cable clip fixed cable.
5.按照接線圖將電纜線各芯線固定在接線盒對應的接線柱或焊點上。
5 according to the wiring diagram will be cable of each core wire is fixed in the terminal box corresponding terminals or solder joints. 注意：不得有虛焊，焊點需用酒精擦凈焊劑。
Note: do not weld, solder joint use alcohol wipe flux.
6.安裝連接件(支承頭涂黃油)和限位支座。松開千斤頂，放平秤臺，蓋上蓋板。
6 install the connector (supporting the head butter) and the limit bearing. Loosen the jack, flat scales, cover.
7.更換傳感器后，必須對地磅重新設定、標正。
The 7 sensor is replaced, must reset is marked, loadometer.
